Filling monoblocco Vir Mauri Pavonis 20.4 Sv

Specifiche tecniche

Used Filling Monoblock Vir Mauri Pavonis 20.4 Sv:
Model: Pavonis 20/4 Sv
Year: 1992
Speed: 4.000 BPH
Direction: Clockwise
Type of bottle: Glass Bottles
FILLER
20 Filling Valves
Manual tank height adjustment
Vacuum before filling
Type of valve: mechanical
CAPPER SCREW CAP
4 heads
Type of workable cap: pressure cap
Cap size: Ø 33 mm; height 46 mm
Head height adjustment: manual
Can also make aluminum screw cap but no equipment (hopper, descent, capping heads)
GENERAL DATA
Supported bottle diameter measurements: Ø 86 mm; Ø 98 mm; Ø 106 mm
Safety protections
Overall dimensions of machinery: length 2150 mm; width 1590 mm; height 2690 mm
